Custody-Transfer Ultrasonic Flowmeters
TSB supplies Custody-Transfer Ultrasonic Flowmeters in Jordan for highly accurate natural gas measurement in transmission pipelines, metering stations, storage facilities and onshore or offshore installations.
Using the ultrasonic transit-time difference principle, these meters measure gas velocity and volumetric flow without introducing mechanical moving parts into the flow stream. Multi-path configurations provide high measurement accuracy, redundancy and advanced diagnostics for fiscal and custody-transfer applications.
Product Overview
Custody-Transfer Ultrasonic Flowmeters combine:
- High-accuracy natural gas custody-transfer measurement
- Ultrasonic transit-time measurement
- 4, 4+1, 4+4 and 8-path configurations
- Pipe sizes from approximately DN80 to DN1400
- Operating pressures up to approximately 450 bar(g)
- Gas temperatures from approximately -46°C to +180°C
- Extended temperatures from approximately -194°C to +280°C on request
- Repeatability of approximately ≤0.05%
- Accuracy down to approximately ±0.1% after suitable flow calibration and correction
- Measurement of natural gas containing up to approximately 30% hydrogen
- Integrated diagnostics
- International custody-transfer approvals
Typical Technical Range
| Specification | Typical Capability |
|---|---|
| Measuring Principle | Ultrasonic transit-time difference |
| Medium | Natural gas and selected process gases |
| Nominal Diameter | DN80 – DN1400 / 3 – 56 in |
| Measurement Paths | 4, 4+1, 4+4 or 8 paths |
| Repeatability | Approximately ≤0.05% of measured value |
| Accuracy | Down to approximately ±0.1% after flow calibration and correction |
| Medium Temperature | Approximately -46°C to +180°C |
| Extended Temperature | Approximately -194°C to +280°C on request |
| Operating Pressure | 0 – 450 bar(g) |
| Hydrogen Capability | Natural gas with up to approximately 30% H₂ |
| Measured Variables | Actual volumetric flow, volume, gas velocity and speed of sound |
| Digital Communication | Modbus TCP |
| Approvals | OIML R137 Class 0.5, AGA Report No. 9, ISO 17089-1, MID and others |
Specifications and available options may vary. Contact TSB for full details and configuration support.
Key Features
- High-accuracy custody-transfer measurement for natural gas
- Multi-path ultrasonic measurement for high reliability
- No mechanically moving components in the gas stream
- Very low pressure loss
- Excellent long-term measurement stability
- Automatic compensation for pressure and temperature influences
- Measurement of natural gas containing hydrogen blends
- Integrated measurement of gas velocity and speed of sound
- Intelligent diagnostics for monitoring measurement quality and process conditions
- Redundant path configurations for increased availability
- Digital pulse and status outputs
- Integration with flow computers and complete metering systems
- Hazardous-area configurations available
- Suitable for high-pressure gas transmission applications
- Onshore and offshore installation capability
Applications
- Natural gas custody transfer
- Fiscal gas metering
- Gas transmission pipelines
- Gas distribution networks
- Metering and regulating stations
- Compressor stations
- Gas storage facilities
- Pipeline entry and exit metering
- Hydrogen-blended natural gas
- Onshore oil and gas facilities
- Offshore gas facilities
- Gas export and import stations
- High-pressure metering skids
- Energy measurement systems
Why Choose Custody-Transfer Ultrasonic Flowmeters?
Custody-transfer gas measurement requires very low measurement uncertainty, high reliability and complete traceability, because even small measurement errors can create significant commercial differences at high flow rates.
Multi-path ultrasonic measurement provides accurate gas velocity measurement across the pipe cross-section while introducing virtually no restriction into the flow. This minimizes pressure loss and eliminates wear associated with mechanically moving metering elements.
Advanced diagnostics continuously monitor acoustic paths, gas conditions and measurement quality, helping operators identify changes in the process or meter condition before they affect measurement performance.
For gas transmission and distribution operators, this provides high measurement accuracy, minimal pressure loss, strong diagnostic capability and reliable long-term custody-transfer performance.
TSB Support in Jordan
TSB supplies Custody-Transfer Ultrasonic Flowmeters throughout Jordan and supports customers in developing complete metering solutions according to pipe size, pressure, gas composition, required accuracy and applicable metrological standards.
Our local support includes:
- Flow meter selection and technical consultation
- Application engineering
- Meter sizing and configuration
- Custody-transfer metering support
- Flow computer integration
- Gas chromatograph and analyzer integration
- Metering skid integration
- Supply and commissioning
- Calibration and verification coordination
- After-sales service
- Spare parts support
- Preventive and corrective maintenance
- On-site technical support
- Troubleshooting assistance
Contact TSB for Custody-Transfer Ultrasonic Flowmeter specifications, selection, pricing and configuration support in Jordan.
