Oxygen Sensors & Transmitters
TSB supplies Oxygen Sensors & Transmitters in Jordan for accurate dissolved oxygen measurement in water, wastewater, utilities, food and beverage, life sciences, chemical and industrial process applications.
Optical and amperometric measuring technologies provide reliable oxygen measurement from trace concentrations to high oxygen levels. Digital sensors and configurable transmitters support continuous process monitoring, aeration control, fermentation, inertization and water quality applications.
Product Overview
Oxygen Sensors & Transmitters combine:
- Continuous dissolved oxygen measurement
- Optical and amperometric sensor technologies
- Measurement from trace oxygen to high concentrations
- Measuring ranges up to approximately 100 mg/L
- Oxygen saturation measurement up to approximately 1000% SAT
- Oxygen partial pressure measurement
- Digital sensor communication
- Single and multi-channel transmitters
- Multiparameter measurement capability
- Fixed, immersion, flow and retractable installations
- Hygienic and hazardous-area configurations
- Analog and digital communication options
Typical Technical Range
| Specification | Typical Capability |
|---|---|
| Measurement | Dissolved oxygen |
| Measuring Principles | Optical or amperometric |
| Oxygen Concentration | Approximately 0.004 – 100 mg/L, depending on sensor |
| Oxygen Saturation | Up to approximately 1000% SAT |
| Oxygen Partial Pressure | Up to approximately 2000 hPa |
| Process Temperature | Up to approximately 80°C in normal operation on selected sensors |
| Sterilization Temperature | Up to approximately 140°C on selected hygienic configurations |
| Process Pressure | Up to approximately 13 bar absolute on selected sensors |
| Sensor Communication | Digital Memosens |
| Transmitter | Single or multi-channel |
| Communication | 0/4–20 mA, HART, PROFIBUS, Modbus, EtherNet/IP, PROFINET and Ethernet depending on transmitter |
| Installation | Immersion, inline, flow or retractable |
Specifications and available options may vary. Contact TSB for full details and configuration support.
Key Features
- Reliable dissolved oxygen measurement across low and high concentration ranges
- Optical sensors for fast, stable measurement and low maintenance
- Amperometric sensors for accurate and linear measurement over wide ranges
- Digital sensor technology for secure signal transmission
- Storage of calibration and process data in the sensor
- Laboratory calibration for simplified field maintenance
- Multiparameter transmitter configurations available
- Oxygen concentration, percentage saturation and partial pressure indication
- Flexible installation in tanks, pipes, basins and open channels
- Hygienic configurations for food, beverage and life sciences
- Hazardous-area configurations for demanding industrial applications
- Calibration and verification accessories available
- Integration with modern process automation systems
Applications
- Wastewater aeration control
- Drinking water monitoring
- Water treatment
- Process water
- Boiler feedwater
- Power plant water systems
- Fermentation
- Inertization
- Food and beverage processing
- Pharmaceutical production
- Biotechnology
- Chemical processes
- Aquaculture and fish farming
- Utilities
- Industrial water systems
- Environmental monitoring
Why Choose Oxygen Sensors & Transmitters?
Dissolved oxygen measurement is essential for process efficiency, product quality, biological treatment and water quality monitoring.
Optical oxygen sensors provide fast and stable measurement with low maintenance requirements, making them well suited to applications where high availability is important. Amperometric sensors provide accurate, linear measurement across wide oxygen concentration ranges and are widely used in wastewater and utility applications.
Digital sensor technology allows calibration and process information to be stored directly in the sensor, simplifying replacement and maintenance while improving measurement reliability.
For plant operators, this provides accurate oxygen measurement, flexible sensor selection, easier maintenance and reliable integration into process control systems.
TSB Support in Jordan
TSB supplies Oxygen Sensors & Transmitters throughout Jordan and supports customers in selecting the appropriate solution according to oxygen range, process medium, temperature, pressure, installation and communication requirements.
Our local support includes:
- Instrument selection and technical consultation
- Application engineering
- Sensor and transmitter configuration
- Assembly selection
- Supply and commissioning
- Calibration and verification support
- System integration
- After-sales service
- Spare parts support
- Preventive and corrective maintenance
- On-site technical support
- Troubleshooting assistance
Contact TSB for Oxygen Sensor & Transmitter specifications, selection, pricing and configuration support in Jordan.
