Hygienic Progressive Cavity Pumps

TSB supplies Hygienic Progressive Cavity Pumps in Jordan for gentle and hygienic transfer of food, beverage, pharmaceutical, cosmetic and other sanitary process products.

The progressing cavity principle provides smooth positive-displacement pumping with low shear and minimal product degradation. This makes hygienic progressive cavity pumps particularly suitable for delicate, viscous and solids-containing products where maintaining product structure, consistency and quality is important.

Product Overview

Hygienic Progressive Cavity Pumps combine:

• Positive-displacement progressing cavity technology
• Gentle, low-shear pumping action
• Hygienic construction for sanitary processes
• Capability for thin to highly viscous products
• Handling of suspended soft solids
• Minimal emulsification and product degradation
• Hygienic process connections
• Food-grade elastomer options
• Clean-in-place (CIP) capability
• Steam-in-place (SIP) compatibility depending on system design
• Quick disassembly for clean-out-of-place procedures
• Duty-specific configurations for food and sanitary processing

Typical Technical Configuration

Specifications and available options may vary. Contact TSB for full details and configuration support.

Hygienic Pumping Principle

Progressive cavity pumps use a helical rotor rotating eccentrically inside a double-helix stator. This creates sealed cavities that move continuously from the suction side toward the discharge.

The resulting flow is smooth and controlled, making the technology especially suitable for products that can be damaged by aggressive pumping action.

Key benefits include:

• Low shear
• Low pulsation
• Gentle handling of solids
• Stable flow across changing viscosities
• Controlled product transfer
• Reduced product emulsification
• Effective handling of viscous media

Gentle Solids Handling

Hygienic Progressive Cavity Pumps are well suited to food products containing soft suspended solids or particulates that should remain intact during transfer.

Typical products can include:

• Diced fruits
• Vegetables
• Soups
• Salsa
• Sauces
• Fruit preparations
• Food mixtures containing soft solids

The low-shear pumping action helps minimize physical damage to the product while maintaining reliable transfer through the process.

High-Viscosity Products

Progressive cavity technology is particularly effective for thick and highly viscous products that can be difficult to move using conventional centrifugal pumps.

Typical applications include:

• Peanut butter
• Jam and preserves
• Confectionery products
• Syrups
• Sauces
• Pastes
• Creams
• Concentrates
• Thick food mixtures

Pump speed, rotor/stator geometry and materials can be selected according to the viscosity and characteristics of the product.

Thin & Low-Viscosity Products

The same technology can also be applied to lower-viscosity products where gentle and controlled transfer is required.

Typical applications include:

• Juices
• Soups
• Beverages
• Vinegar
• Liquid ingredients
• Process water
• Cleaning liquids
• Food additives

This allows one pumping principle to cover a broad range of product viscosities within a hygienic process plant.

Clean-in-Place (CIP)

Hygienic Progressive Cavity Pumps can be incorporated into clean-in-place systems so the internal product-contact surfaces can be cleaned as part of the process line without completely dismantling the pump.

CIP capability can help:

• Reduce cleaning downtime
• Improve repeatability of cleaning procedures
• Reduce manual intervention
• Support hygienic production requirements
• Improve equipment availability

The complete cleaning arrangement should be designed according to the process, product and plant sanitation requirements.

Steam-in-Place (SIP)

Suitable hygienic installations can also be integrated with steam-in-place cleaning systems where thermal sanitation is required.

Materials, elastomers, seals and process connections should be selected according to the required steam temperature, cleaning procedure and hygienic standard.

Clean-Out-of-Place

Where manual inspection or intensive cleaning is required, hygienic pump construction allows the product-contact components to be accessed and disassembled efficiently.

This is useful for:

• Product changeovers
• Allergen-control procedures
• Inspection
• Manual sanitation
• Maintenance
• Applications where CIP alone is not sufficient

Hygienic Design

Hygienic pump configurations are designed to reduce areas where product can accumulate and to simplify cleaning of product-contact components.

Available features can include:

• Hygienic stainless-steel wetted parts
• Sanitary process connections
• Food-grade elastomers
• Smooth product-contact surfaces
• Accessible pump internals
• Hygienic sealing arrangements
• Cleanable rotor and stator components
• Application-specific sanitary configurations

The appropriate hygienic design should be selected according to the product, cleaning regime and required certification.

Applications

• Food processing
• Beverage production
• Dairy processing
• Fruit and vegetable processing
• Sauces and dressings
• Confectionery
• Bakery ingredients
• Juices and concentrates
• Jams and preserves
• Soups
• Syrups
• Cosmetic products
• Personal-care products
• Pharmaceutical processes
• Hygienic chemical processes
• Sanitary product transfer

Why Choose Hygienic Progressive Cavity Pumps?

Hygienic Progressive Cavity Pumps are particularly suited to processes where product quality, hygiene and gentle handling are as important as reliable pumping performance.

The positive-displacement progressing cavity principle can transfer products across a broad viscosity range while maintaining smooth, low-shear flow. Soft solids can be transferred with reduced physical damage, while viscous products can be handled without requiring the high velocities associated with many conventional pumping technologies.

Hygienic construction and flexible CIP, SIP and clean-out-of-place arrangements help simplify sanitation and maintenance.

For food, beverage and sanitary-process operators, this provides gentle product handling, hygienic operation, flexible cleaning and reliable transfer of difficult process products.

TSB Support in Jordan

TSB supplies Hygienic Progressive Cavity Pumps throughout Jordan and supports customers in selecting the appropriate pump according to product viscosity, solids content, required flow, pressure, hygienic requirements and cleaning philosophy.

Our local support includes:

• Pump selection and technical consultation
• Hygienic application engineering
• Pump sizing and configuration
• Product and viscosity evaluation
• Rotor and stator selection
• Elastomer compatibility review
• Hygienic connection selection
• CIP / SIP application support
• Motor and variable-speed drive selection
• Supply and commissioning
• Pump testing support
• After-sales service
• Spare parts support
• Preventive and corrective maintenance
• On-site technical service
• In-house workshop support
• Pump troubleshooting and repair

Contact TSB for Hygienic Progressive Cavity Pump selection, technical specifications, pricing and configuration support in Jordan.
