Flow Computer
TSB supplies Flow Computers in Jordan for accurate gas and liquid metering, flow correction, energy calculation and custody transfer applications. Flow computers combine signals from flow meters, pressure transmitters, temperature sensors and analyzers to calculate corrected volume, mass and energy according to recognized international standards.
Designed for fiscal, custody transfer and allocation measurement, flow computers provide high-accuracy calculations, event logging, parameter logging, reporting and integration with complete metering systems. They are suitable for natural gas, LNG, flare gas, process liquids, CO₂, hydrogen and loading or unloading applications.
Product Overview
Flow Computers combine:
- Gas and liquid volume conversion
- Mass and energy calculations
- Custody transfer and fiscal metering
- Allocation measurement
- Support for up to 4 gas or 4 liquid meter runs per module
- Station configurations for up to 8 meter runs
- High-accuracy analog and pulse inputs
- HART communication
- Event and parameter logging
- Automatic reporting
- Remote access via Ethernet
- International gas and liquid calculation standards
- Modular and redundant system configurations
Typical Technical Range
| Specification | Typical Range |
|---|---|
| Measuring Principle | Flow computer |
| Applications | Gas and liquid metering |
| Meter Runs | Up to 4 gas or 4 liquid runs per module |
| Station Configuration | Up to 8 meter runs |
| Analog Inputs | Up to 6 high-accuracy inputs |
| Analog Input Types | 4–20 mA, 0–20 mA, 0–5 V, 1–5 V |
| Analog Input Resolution | 24 bit |
| HART Inputs | Up to 4 independent loops |
| Pulse Inputs | Up to 4 single or dual pulse inputs, 10 kHz |
| Digital Inputs | Up to 16 |
| Analog Outputs | Up to 4 |
| Digital Outputs | Up to 16 |
| Communication | RS232, RS485, Ethernet TCP/IP, HART |
| Power Supply | 24 VDC ±10% |
| Ambient Temperature | Approximately -40°C to +75°C, depending on configuration |
Specifications and available options may vary. Contact TSB for full details and configuration support.
Key Features
- High-accuracy flow conversion for fiscal and custody transfer applications
- Gas and liquid volume, mass and energy calculations
- Integration with ultrasonic, Coriolis and other flow meter technologies
- Pressure, temperature, density and composition compensation
- Multiple meter-run configurations
- High-resolution analog and pulse signal processing
- Event, alarm and parameter logging
- Automatic reporting and historical data storage
- Remote access via Ethernet
- HART transmitter integration
- Redundant system configurations available
- Modular architecture for future expansion
- Tamper protection for critical metering parameters
- Local visualization and web-based interfaces on applicable configurations
- Hazardous-area configurations available
Calculation Standards
Flow Computers support a wide range of internationally recognized calculation methods and metering standards, including:
- AGA 5
- AGA 8
- AGA 10
- AGA NX-19
- GERG-2008
- ISO 6976
- ISO 12213
- API MPMS calculation methods
- OIML requirements
- MID metering requirements
This allows the system to be configured according to the specific gas or liquid composition, metering standard and commercial requirements of the application.
Applications
- Natural gas metering stations
- Custody transfer metering
- Fiscal metering
- Allocation metering
- LNG measurement
- Flare gas measurement
- Hydrogen measurement
- CO₂ measurement
- Oil and liquid hydrocarbon metering
- Loading and unloading systems
- Pipeline metering
- Gas transmission and distribution
- Metering skids
- Compressor stations
- Onshore facilities
- Offshore facilities
- Process fluid measurement
Why Choose a Flow Computer?
A Flow Computer is a critical component of a complete metering system where raw flow measurement must be converted into accurate standardized volume, mass or energy values.
The system receives measurement signals from the flow meter together with pressure, temperature, density or gas composition information. It then applies the required compensation and standardized calculation methods to determine the commercial flow quantity.
For custody transfer and fiscal applications, integrated logging and reporting also provide traceability of measured values, parameter changes, alarms and events.
For operators and metering system integrators, this provides accurate flow conversion, standardized calculations, secure data management and reliable integration of the complete metering system.
TSB Support in Jordan
TSB supplies Flow Computer solutions throughout Jordan and supports customers in developing complete flow metering systems according to the required measurement standard, meter technology, communication architecture and commercial application.
Our local support includes:
- Flow computer selection and configuration
- Metering application engineering
- Gas and liquid calculation configuration
- Flow meter and transmitter integration
- Custody transfer and fiscal metering support
- Metering skid integration
- Communication and system integration
- Supply and commissioning
- After-sales service
- Spare parts support
- Preventive and corrective maintenance
- On-site technical support
- Troubleshooting assistance
Contact TSB for Flow Computer specifications, metering system design, pricing and configuration support in Jordan.
